Hygienic Magnetic Flow Meter

Hygienic Magnetic Flow Meter

The MFI447 from GHM Messtechnik offers an EHEDC certified hygienic flow meter available in 14 diameters to cope with flows from 5l/hr to 283M3/hr.

The compact design and variety of process connections leads to its easy incorporation into any hygienic installation.

The magnetic flowmeter is powered by a 24VDC supply and operated by four buttons from its integral LCD display

The advantage of MFI447 are

  • No moving parts
  • Compact transmitter
  • Low pressure loss
  • Hygienic all stainless steel design for Pharmaceutical & Food applications
  • Suitable for flow measurement of all conductive liquids and pastes
  • Available with a variety of process connections
  • Automatic batch processing features
  • Accuracy of 0.5%
  • Can measure forward and backwards flows
  • Integral back-lit display gives local display of process flow
  • Protection class IP67/IP69
  • CIP/SIP cleanable up to 150

Magnetic field diagram

Typical applications include

  • Metering of all liquid, pulpy and pasty media with a minimum conductivity of >5S/cm
  • Flow range from 5l/hr up to 283 M3/hr
  • Monitoring of CIP or filtration processes
  • Basic filling and metering tasks
